| Displacement |
47.8 |
| Engine |
Single Cylinder, 4 Stroke |
| Bore & Stroke |
39×40 |
| Cooling System |
Air Cooled |
| Compression Ratio |
8.8:1 |
| Fuel feed |
90# |
| Max Power( Kw/rpm) |
2.18/7500 |
| Max Torque(N.M/rpm) |
3.74/4500 |
| Max Speed |
65 kmph |
| Ground clearance |
125 mm |
| Fuel consumption |
1.8L/100KM |
| Drive Train |
CVT |
| Ignition |
CDI |
| Transmission |
chain |
| Fuel tank capacity |
5.0L |
| Starting System |
Electric+kick start |
| Front Brakes |
Drum brake |
| Rear Brake |
Drum brake |
| Front suspension |
Hydraulic Suspension |
| Rear suspension |
Hydraulic Suspension |
| Wheel |
Iron |
| Front tires |
3.75-12 |
| Rear tires |
4.00-12 |
| Wheel Base |
1180 mm |
| Seat Height |
750mm |
| Payload |
156kg |
| Net Weight |
200KG |
| Gross Weight |
210KG(CKD) |
| Packing type |
Steel + Carton |
| Carriage Size |
1300*900*270mm |
| Packing size |
```````````````````` |
| 40’ HQ container |
60 units(CKD) | |
